| Rated Capacity: | |
|---|---|
| Rated Voltage: | |
| Weight: | |
| Availability: | |
| Quantity: | |
| Item | Parameter | Remark |
| Rating Voltage | 51.2V | |
| Capacity | 100Ah | 0.2C discharge after full charge |
| minimum capacity | ≥100Ah | 0.2C discharge after full charge |
| communication mode | With bluetooth | optional |
| Charge Voltage | 58.4V | |
| Rated Charge current | ≤20A | Maximum Charge current：100A |
| Impedance | ≤30mΩ（Max） | |
| Charging Mode | CC/CV | Constant Current /Constant Voltage |
| Charging Method | Standard Charging 0.2C | Charging Current:20A |
| Fast Charging0.5C | Charging Current :50A | |
| Charging Time | About 5Hours | Standard Charging |
| About 2Hours | Fast Charging | |
| Overcharge Voltage | 3.65V /Cell | Single string voltage（adjustable） |
| Over Discharge Cut Off Voltage | 2.8V /Cell | Single string voltage（adjustable） |
| Rated discharge current | ≤50A | Maximum discharge current |
| Over Current | 110A | |
Short Circuit | Recover after removing the short circuit load | |
| Operating Consumption Current | 50mA (Max) | |
| Operating Temperature | +10~+45℃ | Charging |
| -20~+60℃ | Discharging | |
| Storage Temperature | -20℃-50℃ (Recommend) | Storage capacity should be 60±25%R.H full charge capacity |
| Cycle Life | 3000 cycle | Percentage of recoverable capacity 80% |
| Dimensions | 520*269*220mm | External dimensions of the chassis, excluding handles and terminals. |
| Weight | ≥ 36 kg | Subject to actual product weight |
| Shipped product charge | 50%-60% battery volume delivery 50%-60% | |
| Package material | Carton + wooden fumigation tray |
