Product Description
We insist on using A-grade original battery cells and the best lithium battery solutions to meet customers' needs, which keeps safety and durability in mind and is committed to creating long lifespan, powerful, weather-resistant, and cost-efficiency also to meet the market demands, providing millions of electric vehicle users to bring lightweight, convenient, fast, smart, and sustainable new energy experience.
|
Application
| Data Sheet
Item | Parameters |
Rated volatge | 64V |
Rated capacity | 30Ah |
Dimension(L*W*H) | 218*167*273 mm |
Voltage range | 48V-73V |
SOC | 0-100% |
Working temperature | -20°C-55°C |
Discharge current | 30A |
Charge temperature | 0°C-55°C |
Charge current | 15A |
Charge voltage | 73V |
| Advantages and features
1. Adopting long-life and high-safety lithium iron phosphate battery cells;
2. Adopting double-layer design of inner and outer shells, with high protection level;
3. The whole package is small in size, light in weight and low in power consumption;
4. We are a supplier with excellent design and rich experience, meeting various requirements of customers
5. Long service life
6. High temperature good performance
7. No memory effect
8. Light weight and environmental protection
|
Comment & FAQ
1. What is the cells you used for the battery?
A: We choose the cells on your need, now mostly we use 21Ah, 30Ah,52Ah,63Ah Gotion A level cells for this kind of battery pack. All pack cells our required is A and will be test before make module.
2. Have MOQ on this product?
A: yes, we have MOQ for the scooter battery is 100 sets.
3. Will my existing charger still work?
A: May not, If you have used a lead-acid charger before, it is definitely not suitable for our lithium batteries. If you have used a lithium battery charger before, it may not be suitable for our batteries. It is recommended to use our original charger. It is more conducive to the safety of the battery.
4. How do you ensure the quality of the batteries I buy?
A: First of all, our batteries are original A-grade batteries with data. Secondly, we have quality control and testing at every step in the entire production process. Finally, we will give you the capacity test data of the battery pack.
5. What about the warranty period?
A: We will give customers a three-year warranty period, but it does not include man-made damage to the battery and force majeure such as natural disasters, etc.
|
Available Models
Model | GP6020 | GP6030 | GP6040 | GP6050 | GP6060 | GP60100 | GP60105 | |
Electrical Characteristics | Rate Vlotage(AH) | 64 | 64 | 64 | 64 | 64 | 64 | 64 |
Rate capacity(AH) | 21 | 30 | 42 | 52 | 60 | 100 | 105 | |
Built in BMS(Yes/No) | yes | |||||||
Cycle life | DOD(≥1800 cycles to 85% DOD). | |||||||
Months self discharge | ≤2% | |||||||
Efficiency of charge | 100% at 0.2C | |||||||
Efficiency of discharge | 96~99% at 1C | |||||||
Standard Chage | Charge voltage | 73±0.2V | ||||||
Charge mode | 0.2C to 73V, then 73V, charge current to 0.02C (CC/CV) | |||||||
Charge current(A) | 4 | 6 | 8 | 12 | 12 | 20 | 20 | |
Max.charge current(A) | 5 | 9 | 12 | 18 | 18 | 30 | 30 | |
Charge cut-off voltage(VDC) | 69.35±0 . 2V | |||||||
Standard Dischage | Contiunous current(A) | 4 | 6 | 8 | 12 | 12 | 20 | 20 |
Discharge cut-off voltage(VDC) | 73±0.2V | |||||||
Environment | Charge temperature | ![]() | ||||||
Discharge temperature | -20 ℃ to60 ℃ (-4F to 140F) @60±25% Relative Humidity | |||||||
Storage temperature | 0℃ to40 ℃ (32F to104F) @60±25% Relative Humidity | |||||||
Mechanical | IP class | IP63-IP65 | ||||||
Material system | LFP | |||||||
Case material | Metal | |||||||
Dimensions: L*W*H(mm) | Custo | Custom | Custom | Custom | Custom | Custom | Custom | |
Weight(kg) | 22 | 40 | 42 | 44 | 45 | 46 | 48 | |
Protocol(Optional) | SMBUS/RS485/RS232 | |||||||
SOC(Optional) | NONE | |||||||
Warranty period | 36 months |
