Custom Battery Pack
Pls go to our dwonload page to check a sheet Product research form.Your info will do a big hlep to us.
| Model | HY4-3.5T |
| Rated Capacity | 150Ah |
| Rated energy | 56KWh |
| Rated voltage | 374.4V |
| Working voltage range | 292.5-427V |
| working temperature range | Charge：0-55℃ , Discharge：-20-55℃ |
| Maximum Continuous Discharge Current | 150A |
| Maximum pulse discharge current | 300A/60S |
| Maximum continuous charging current | 150A |
| heating power | 3000W |
| heating method | PTC heating |
| heating efficiency | Temperature rise 10℃/h |
| System weight | 460±20kg |
| Size | 950*550*750mm |
