Product Description
Introducing our Golf Cart Batteries - the epitome of reliable and efficient energy storage for your golfing adventures. Engineered with cutting-edge technology, these batteries are crafted to deliver superior performance and longevity on the golf course.
|
Comment & FAQ
|
Data Sheet
Core Material | LiFePO4 | LiFePO4 | |
Nominal Voltage | 51.2V | 51.2V | |
Rated Capacity | 240Ah |
| |
Energy Capacity | 12288wh | 3686wh | |
Maxium Charge / Discharge Current | 240A | 67A | |
Scalable (Parallel Function) | YES | YES | |
Cycle Life (25℃ 0.5C) | 3000 times | 3000times | |
Charging Mode (CC/CV) | CC/CV | CC/CV | |
Max Charge Current | Max1C @25℃ | Max1C@25℃ | |
Discharge Mode | CC/CV | CC/CV | |
Discharge Current | 0.5C@25℃ | 0.5C@25℃ | |
Max Discharge Current | Max1C @25℃ | Max1C @25℃ | |
Discharge Working Temperature Range | -20 +55℃ | -20 +55℃ | |
Storage Environment | 25±5℃ | 25±5℃ | |
Net Weight | 105KGS | 35KGS | |
Dimension (L*W*H) mm | 810*254*254 | 381 * 260 *265 | |
Application | Golf cart | Golf cart | |
Battery Warranty | Standard 3 years | ||
|
Advantages and Features
1. Long-Lasting Power: Our batteries are designed to provide consistent and long-lasting power to keep your golf cart running smoothly throughout your game.
2. Efficient Energy Storage: With advanced energy storage technology, these batteries ensure optimal efficiency, allowing you to cover more distance on a single charge.
3. Quick Charging: Experience minimal downtime with our fast-charging technology. Spend more time on the golf course and less time waiting for your batteries to recharge.
4. Durable Design: Built to withstand the rigors of the golfing environment, our batteries feature a rugged and durable design that can handle various terrains and conditions.
5. Maintenance-Free: Enjoy hassle-free ownership with our maintenance-free batteries. Focus on your game without worrying about constant upkeep.
6. Compatibility: PowerPro batteries are compatible with a wide range of golf carts, making them a versatile choice for golf enthusiasts.
|
Comment & FAQ
1.What are your trade terms and payment terms?
A:We welcome most of the regular trade terms, such as EXW, FOB, CIF, DDU, etc.
Normally we would insist a Min. 30% advance payment to effect your order, and the balance 70% must be settled after your acceptance of the finished products and before delivery.
2.Do you provide warranty, if yes, how long?
A:Yes, generally we will provide three-year warranty for all battery packs we offer. However, buyers can request longer warranty period before placing orders.
3.Can I leave your batteries outside?
A:No. Our batteries are not marine rated or weather proof, so leaving them out under the sun all day or in the rain can damage the batteries. (This type of damage is not covered under the warranty.
4.Can you accept OEM and ODM Service?
A:Yes, we supply OEM&ODM service as clients requirement.
5.How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production and Shipping.
|
Avaliable Models
MODEL | GP7230 | GP7240 | GP7260 | GP7270 | GP7275 | GP7280 | GP72100 | GP72125 | GP72140 | GP72180 |
Rate voltage(Vdc) | 72 | 72 | 72 | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
Rate capacity(AH | 30 | 40 | 60 | 70 | 75 | 80 | 100 | 125 | 140 | 180 |
Energy storage(KWH) | 2.16 | 2.88 | 4.32 | 5.04 | 5.4 | 5.76 | 7.2 | 9 | 10.08 | 12.96 |
Built in BMS(Yes/No) | Yes | |||||||||
Cycle life | DOD(≥1800 cycles to 85%DOD). | |||||||||
Months self discharge | ≤2% | |||||||||
Efficiency of charge | 100%at 0.2C | |||||||||
Efficiency of discharge | 96~99%at 1C | |||||||||
Charge voltage | 83.95±0.2V | |||||||||
Charge mode | 0.2C to 83.95V,then 83.95V,charge current to 0.02C (CC/CV) | |||||||||
Charge current(A) | 6 | 8 | 12 | 14 | 15 | 16 | 20 | 25 | 28 | 36 |
Max.Charge current(A) | 9 | 12 | 18 | 21 | 22.5 | 24 | 30 | 37.5 | 42 | 54 |
Charge cut-off voltage(VDC) | 83.95±0.2V | |||||||||
Contiunous current(A) | 6 | 8 | 12 | 14 | 15 | 16 | 20 | 25 | 28 | 36 |
Discharge cut-off voltage(VDC) | 83.95±0.2V | |||||||||
Charge temperature | 0 ℃to 45 ℃(32F to 113F)@60±25%Relative Humidity | |||||||||
Discharge temperature | -20 ℃ to 60 ℃(-4F to 140F)@60±25%Relative Humidity | |||||||||
Storage temperature | 0°℃to 40 ℃(32F to 104F)@60±25%Relative Humidity | |||||||||
IP class | IP63 | |||||||||
Material system | LiFePO4 | |||||||||
Case material | Metal | |||||||||
Dimensions:W*H*D(mm) | 360*210*180 | |||||||||
Weight | ||||||||||
Terminal | M8 | |||||||||
Protocol(Optional) | SMBus/RS485/RS232 | |||||||||
SOC(Optional) | NONE | |||||||||
The quality assurance period | 60 months | |||||||||
