Product Description
It has elegant design and wide application range.Our battery can provide professional and high-quality system solutions for solar / wind energy, communication base station, ups and engine startup.OEM services of communication lithium battery cabinet, home solar energy storage system, portable power supply system, container energy storage system, electric energy storage system, etc is available.
|
Application
Grid frequency adjustment energy storage system
New energy communication base station, Core computer room, IDC ,UPS
New energy generation (solar, wind, PV/wind hybrid) access to energy storage system
Smart grid, micro-grid system
Mobile container storage system
Other energy Storage System
Peak load shifting energy storage system
Load tracking energy storage system
|
Data Sheet
Rated Voltage | 12.8V |
| Rated Capacity | 100Ah |
| Application | Hospital, bank data center, wall-mounted home, New energy communication base station… |
Cycle Life | 6000 times @ 25℃ |
Charging Mode (CC/CV) | CC/CP/VP |
Charging Current | 0.2C (Standard) |
Charge Cut Off Voltage | 14.6V/CELL |
Max Charge Current | Max0.5C @25℃ |
Discharge Cut Off Voltage | 11.2V |
Discharge Mode | CC/CP/VP |
Discharge Current | 0.5C@25℃ |
Max Discharge Current | Max1C @25℃ |
Charge Working Temperature Range | 0~+50℃ |
Discharge Working Temperature Range | -20 +55℃ |
Storage Environment | 25±5℃ |
Warranty | 5 years |
Net Weight | 20.6KGS |
Dimension (L*W*H) | 325*450(492)*133 |
|
System Advantages
1.High cycle times,5000 cycles to 80% DOD(23500 cycles to 100% DOD)Others is with up to 3000 cycles to 80% DOD(≥2000 cycles to 100% DOD).
2.Low self-discharge rate (per month):≤ 2%
3.Easy installation, the battery can be installed in 19" standard cabinet or wall-mounted
4.Convenient interface design, all wiring harness is connected with plug.
5.Wide operating temperature range (-20~+60℃) and good high temperature performance.
6.Excellent fast charging performance, afler fast charging wih 1C current, the capacity can reach 95% of rate capacity in half-hour.
|
Comment & FAQ
1.Is the battery safe?
A:Yes,Our products have strict quality inspections before sending,It uses high-quality battery cells. Due to the BMS system, there will be no explosion to protect your safety.
2.What are the advantages of your company?
A:Strong R & D team, independent R & D and production of main parts, to control product quality from the source.
3.Can you supply OEM &ODM service ?
A:Yes, Welcome to contact us for more information.
4.How do you ship the goods since they are high capacity battery ?
A:We have long-term cooperated forwarders who are professional at battery shipment.
|
Avaliable Models
MODEL | GP2450R | GP24100R | GP24120R | GP24150R | GP24200R |
Rate voltage(Vdc) | 25.6 | 25.6 | 25.6 | 25.6 | 25.6 |
Rate capacity(AH) | 50 | 100 | 120 | 150 | 200 |
Energy storage(KWH) | 1.28 | 2.56 | 3.072 | 3.84 | 5.12 |
Cycle life | ≥6000 cycles @85%DOD | ||||
Months self discharge | ≤2% | ||||
Efficiency of charge | 100%at0.2C | ||||
Efficiency of discharge | 96-99%at 1C | ||||
Charge voltage | 29.2±0.2V | ||||
Charge mode | 0.2C to 29.2V,then 29.2V,charge current to 0.02C (CC/CV) | ||||
Charge current(A) | 10 | 20 | 24 | 30 | 40 |
Max.Charge current(A) | 50 | 100 | 120 | 150 | 200 |
Charge cut-off voltage(VDC) | 22.4 | ||||
Contiunous current(A) | 50 | 100 | 120 | 150 | 200 |
Discharge cut-off voltage(VDC) | 22.4 | ||||
Charge temperature | 0℃to45℃(32F to 113F)@60±25%Relative Humidity | ||||
Discharge temperature | -20 ℃to 60 ℃(4F to 140F)@60±25%Relative Humidity | ||||
Storage temperature | 0℃to 40℃(32F to 104F)@60±25%Relative Humidity | ||||
IP class | IP63 | ||||
Material system | LiFePO4 | ||||
Case material | Metal | ||||
Pack Dimensions L*W*H(mm) | 325*440(482)*137 | 475*450(492)*133 | 470*440(482)*177 | 471*440(482)*266 | 471*440(482)*266 |
Package Dimension L*W*H(mm) | 410*515*215 | 545*530*215 | 565*515*255 | 565*535*360 | 565*535*360 |
Net Weight(kg) | 20.0 | 24.7 | 26.4 | 30.8 | 43.4 |
Gross Weight(kg) | 21.5 | 28.0 | 28.9 | 33.6 | 47.3 |
Terminal | M8 | ||||
Protocol(Optional) | CANBus/RS485/RS232 | ||||
SOC(Optional) | LED/LCD | ||||
The quality assurance period | 60 months | ||||
MODEL | GP4850LR | GP4880LR | GP48100LR | GP48120LR | GP48150LR | GP48200LR |
Rate voltage(Vdc) | 48 | 48 | 48 | 48 | 48 | 48 |
Rate capacity(AH) | 50 | 80 | 100 | 120 | 150 | 200 |
Energy storage(KWH) | 2.4 | 3.84 | 4.8 | 5.76 | 7.2 | 9.6 |
Cycle life | ≥6000 cycles to 85%DOD | |||||
Months self discharge | ≤2% | |||||
Efficiency of charge | 100%at 0.2C | |||||
Efficiency of discharge | 96-99%at 1C | |||||
Charge voltage | 54.75 | |||||
Charge mode | 0.2C to 54.75V,then 54.75V,charge current to 0.02C (CC/CV) | |||||
Charge current(A) | 10 | 16 | 20 | 24 | 30 | 40 |
Max.Charge current(A) | 50 | 80 | 100 | 120 | 120 | 200 |
Charge cut-off voltage(VDC) | 54.8 | |||||
Contiunous current(A) | 50 | 80 100 | 120 | 120 | 200 | |
Discharge cut-off voltage(VDC) | 42 | |||||
Charge temperature | 0℃to45℃(32F to 113F)@60±25%Relative Humidity | |||||
Discharge temperature | -20 ℃ to 60 ℃(4F to 140F)@60±25%Relative Humidity | |||||
Storage temperature | 0℃to 40℃ (32F to 104F)@60±25%Relative Humidity | |||||
IP class | IP63 | |||||
Material system | LiFePO4 | |||||
Case material | Metal | |||||
Case Type | Rack Mount | |||||
Pack Dimensions L*W*H(mm) | 400*440(482)*150465*440(482)170480*440(482)*177570440(482)177500*440(482)*260 | 550*440*250 | ||||
Package Dimension L*W*H(mm) | 545*525*255 | 560*515*265 | 585*515*345 | 585*515*345 | 575*515*335 | 680*470*350 |
Net Weight(kg) | 22.1 | 44.9 | 49.8 | 51.2 | 57.2 | 80.0 |
Gross Weight(kg) | 24.7 | 47.7 | 52.5 | 53.6 | 60.3 | 84.5 |
Terminal | M8 | |||||
Protocol(Optional | CANBus/RS485/RS232 | |||||
SOC(Optional) | LED/LCD | |||||
The quality assurance period | 60 months | |||||
MODEL | GP4850HR | GP4880HR | GP48100HR | GP48120HR | GP48150HR | GP48200HR |
Rate voltage(Vdc) | 51.2 | 51.2 | 51.2 | 51.2 | 51.2 | 51.2 |
Rate capacity(AH) | 50 | 80 | 100 | 120 | 150 | 200 |
Energy storage(KWH) | 2.56 | 4.096 | 5.12 | 6.144 | 7.68 | 10.24 |
Cycle life | ≥6000 cycles to 85%DOD | |||||
Months self discharge | ≤2% | |||||
Efficiency of charge | 100%at0.2C | |||||
Efficiency of discharge | 96-99%at 1C | |||||
Charge voltage | 58.4 | |||||
Charge mode | 0.2C to 58.4V,then 58.4V,charge current to 0.02C (CC/CV) | |||||
Charge current(A) | 10 | 16 | 20 | 24 | 30 | 40 |
Max.Charge current(A) | 50 | 80 | 100 | 120 | 120 | 200 |
Charge cut-off voltage(VDC) | 58.4 | |||||
Contiunous current(A) | 50 | 80 | 100 | 120 | 120 | 200 |
Discharge cut-off voltage(VDC) | 44.8 | |||||
Charge temperature | 0℃to45℃(32F to 113F)@60±25%Relative Humidity | |||||
Discharge temperature | -20℃to 60℃(-4F to 140F)@60±25%Relative Humidity | |||||
Storage temperature | 0℃to 40 ℃(32F to 104F)@60±25%Relative Humidity | |||||
IP class | P63 | |||||
Material system | LiFePO4 | |||||
Case material | Metal | |||||
Case Type | Rack Mount | |||||
Pack Dimensions L*W*H(mm) | 451*450(492)*177 | 465*440(482)*19 | 490*440(482)*19 | 490*440(482)*19 | 490*442(484)*250550*442(482)*250 | |
Package Dimension L*W*H(mm) | 545*525*255 | 560*515*265 | 585*515*345 | 585*515*345 | 575*515*325 | 600*600*325 |
Net Weight(kg) | 24.6 | 33.6 | 52.8 | 54.6 | 64.5 | 88.5 |
Gross Weight(kg | 26.2 | 36.8 | 55.6 | 56.2 | 67.0 | 92.7 |
Terminal | M8 | |||||
Protocol(Optional) | CANBus/RS485/RS232 | |||||
SOC (Optional) | LED/LCD | |||||
The quality assurance period | 60 months | |||||
