High-efficiency liquid cooling technology with a temperature difference ≤4°C
280AH large single batteries, adopting laser welding process.
Outdoor integrated cabinet design, IP54, directly installed outdoors.
Advanced heat insulation refractory, provides fire resistance.
Enabling direct outdoor installation.
|
Application
The product integrates batteries, BMS, air conditioners and fire protection systems. It can be widely used in substations, small industrial and commercial, hospital buildings, charging stations, household electricity and other occasions, and has the functions of peak load shaving, combined with new energy power generation, dynamic capacity expansion, demand management, power quality management, emergency backup power, etc.
|
Data Sheet
| Model | E400-HSN-ESS
|
| Energy storage capacity | 372kWh |
Rated power
| 200kW |
| Connected to the power grid parameters | 380Vac@50Hz |
| Auxiliary power supply | ～7.5kW |
Battery management system
| Integration |
| Battery type | Lithium iron phosphate battery |
| Maximum charge discharge rate | 0.5C/0.5C（Sustainable） |
| Cooling method | Liquid cooling |
| Electrical box protection level | IP65 |
| Working temperature | -25～55°C |
| Relative humidity | 0～95%，Non-condensing |
| Fire protection system | Precision fire protection（Can reach the level of electrical box） |
| Operating temperature difference | ≤4°C |
| Battery compartment protection level | IP54 |
Communication methods
| Ethernet（Optional configuration4G）
|
| Main configurations | 280AhCell, PCS system, liquid cooling system, fire protection system |
| Size | 1800*1250*2400 |
| Weight | ～3.5T |
| Cell model | 3.2V280Ah |
| Cell cycle life | ≥8000Times（25°C，0.5CCharging and discharging） |
|
System Advantages
All in one design, high integration.Compact size, high power density
High efficiency and stabability
Commercial and Industrial application
Versatile application scenarios, improve quality of power supply
Safety and reliable
Support coordination of BMS and EMS
|
Comment & FAQ
1. Do you have any MOQ limit?
A: Yes. In general, MOQ is 1 set.
2. Factory or Trading?
A: We are a manufacturer specializing in lithium-ion batteries.
3. Can you OEM and ODM Service?
A: Yes, we can provide free OEM Service and ODM Service. We can design the packaging and logo according to your requirements.
4. Do you test all your goods before delivery?
A: Yes, all our products have been tested before delivery.
5. How do you ship the goods since they are high capacity battery ?
A:We have long-term cooperated forwarders who are professional at battery shipment.
