Gotion
| Nominal Voltage: | |
|---|---|
| Nominal Capacity: | |
| Charge Tempereture Range: | |
| Discharge Temperature Range: | |
| ChargeTemperature Currunt: | |
| Quantity: | |
Item | Parameters | Conditions/Comments |
2.1.1 Nominal Capacity | ≥53.5Ah | 0.33C |
≥52Ah | 1C | |
2.1.2 Nominal Voltage | 3.2V | 0.33C |
3.1V | 1C | |
2.1.3 Charge/Discharge Voltage Window | 2.0V～3.65V | >0℃ |
1.8V～3.65V | ≤0℃, continuous charging is not allowed | |
2.1.4 Weight | 966g±30g | Without outer film |
2.1.5 Weight Energy Density | ≥175Wh/kg | 0.33C/0.33C |
2.1.6 Volume Energy Density | ≥350Wh/L | 0.33C/0.33C |
2.1.7 AC Resistance | 0.5mΩ≤R≤0.8mΩ | 25℃±2℃ |
2.1.8 DC Resistance | ≤2.5mΩ | 50%SOC，25℃ ±2℃ |
Precautions
1.When using a device equipped with a battery, refer to the user manual before use.
2.Check the orientation of the cathode and anode terminals before packaging.
3.The terminal or wire is connected to the cell module, pay attention to the insulation to prevent short circuit.
4.Store the cell in a cool dry place (≤35°C, 30%~50%SOC, charge and discharge once every 3 months) when not in use for a long time.
5. Do not place the cell in direct sunlight or heat source to prevent high temperature of the cell.
6.Do not wear metal accessories (such as rings, watches, accessories, etc.) when handling cell units..
7.Do not place the cell outside the operating temperature range specified in this document.
